Apparel & cap badges
Produce raised TPU badge transfers using the appropriate media, artwork and finishing process.
Original price was: £11,000.00.£9,350.00Current price is: £9,350.00.
+vat
Best for: roll-fed UV TPU badges and UV crystal-label production.
Use a wider film format for raised badge transfers and crystal-label work, with the setup selected for the intended output.
TPU badges use printing, cutting and heat pressing. Crystal labels use a separate compatible film and transfer process.
Prices exclude VAT.
UV TPU badges & crystal labels
The GD-600S, also known as the 600 Super, is a roll-fed UV printer for TPU badge transfers and crystal labels. Its 600 mm maximum media width gives you room to arrange multiple designs across the film.
What you can make
Produce raised TPU badge transfers using the appropriate media, artwork and finishing process.
Develop embroidery-effect or textured designs with a suitable production setup and an approved sample.
Create transfer graphics for compatible products and surfaces using the correct crystal-label films and application process.
Application examples depend on the correct configuration, consumables and finishing process. Test the actual material before production.
Know the machine
| Specification | Details |
|---|---|
| Printing format | Roll-fed UV film printing |
| Supported output | UV TPU badges and UV crystal labels; workflow-dependent |
| Maximum media width | 600 mm |
| Maximum media thickness | 1.5 mm |
| Printhead options listed | 3 or 4 Epson I1600-U1 / I3200-U1 heads; confirm quoted configuration |
| Ink | Grando UV ink: CMYK + white + varnish |
| Maximum resolution listed | 2400 dpi |
| Curing | Dual UV LED lights |
| Interface | Gigabit Ethernet |
| Weight with stand | 200 kg |
| Listed power | 3500 W |
| Power supply | AC 220 V ±10%, 50/60 Hz |
| Operating environment | 15–32°C; 35–80% RH, no condensation |
The figures above reproduce the manufacturer specifications listed on this product page. Confirm the supplied configuration and installation requirements in your itemised quotation.
From artwork to finished item
Choose TPU badges or crystal labels, then confirm the matching media, head configuration and artwork requirements.
Use the confirmed CMYK, white and varnish setup with the correct production preset.
TPU badges require the specified cutting and double heat-press process. Crystal labels require their own compatible transfer and application workflow.
Before you order
An application or optional fixture shown in the catalogue does not establish what is included. Have the supplied equipment, consumables, software and services clearly itemised.
Confirm whether the quotation uses three or four heads and the exact Epson I1600-U1 or I3200-U1 configuration.
Itemise media, cutting equipment and the heat-press arrangement for badge production.
Specify the compatible films, consumables and finishing stages for crystal-label work.
Confirm the complete footprint, power requirements and RIP licence, and request samples for the intended finish and substrate.
A few useful answers
Match the machine to your actual materials and finished product. A representative sample can help confirm the setup you need.
The GD-600S is also known as the 600 Super in this range.
Both applications have been confirmed. Each requires the appropriate configuration, consumables and finishing process.
The GD-600S is a roll-fed film printer. For direct-object work alongside transfer applications, compare the GD-6090UV Pro.
The published figure is maximum media width. Confirm the usable printable width and margins for the quoted configuration.
No. Each application needs its own compatible media and finishing method. Specify both workflows in the quotation if you intend to offer both.
Related products
Compare the relevant supplies, services and alternative equipment below. Confirm consumable compatibility with the exact configuration before ordering.
CMYK and white options. Confirm compatibility with the exact head and media setup.
A separate clear-finish ink product. Confirm the approved formulation and application.
Explore artwork preparation for the intended finish; machine-specific requirements still need confirmation.
600 × 900 mm flatbed for suitable objects and separately specified transfer work.
Talk through your application
Tell us whether you need TPU badges, crystal labels or both. Include your design sizes, intended substrates and finishing requirements.
Discuss your setupCall 01324 610156 or email sales@dtfsupplies.co.uk.
The Grando GD-600S, also referred to as the 600 Super, is a roll-fed UV printer for TPU badge transfers and UV crystal labels. Its 600 mm maximum media width provides space for multiple designs across the film.
The manufacturer sheet documents the TPU badge process; supplier clarification also confirms crystal-label capability. Select the media, head configuration and finishing stages around the output you need.
| Specification | Details |
|---|---|
| Printing format | Roll-fed UV film printing |
| Supported output | UV TPU badges and UV crystal labels; workflow-dependent |
| Maximum media width | 600 mm |
| Maximum media thickness | 1.5 mm |
| Printhead options listed | 3 or 4 Epson I1600-U1 / I3200-U1 heads; confirm quoted configuration |
| Ink | Grando UV ink: CMYK + white + varnish |
| Maximum resolution listed | 2400 dpi |
| Curing | Dual UV LED lights |
| Interface | Gigabit Ethernet |
| Weight with stand | 200 kg |
| Listed power | 3500 W |
| Power supply | AC 220 V ±10%, 50/60 Hz |
| Operating environment | 15–32°C; 35–80% RH, no condensation |
Figures above are manufacturer specifications. Confirm the supplied configuration and installation requirements in your quotation.
For TPU badges, the sheet specifies design, printing, cutting and double heat pressing. Plan for compatible media, cutting and pressing equipment, and test the finished badge on the intended fabric.
Crystal labels need their own compatible film and application process. Confirm the ink setup, consumables and finishing stages for this mode.
Your quotation should identify the head type and count, RIP licence, consumables, finishing equipment and installed footprint. Ask for application samples where finish, flexibility or adhesion is important.
The GD-600S is also known as the 600 Super in this range.
Both applications have been confirmed. Each requires the appropriate configuration, consumables and finishing process.
The GD-600S is a roll-fed film printer. For direct-object work alongside transfer applications, compare the GD-6090UV Pro.
Tell us what you want to print, the material and dimensions, and your expected order volume. Ask for an itemised quotation, call 01324 610156 or email sales@dtfsupplies.co.uk.
