Gifts & promotional items
Decorate suitable phone cases, gifts and other objects after checking their dimensions and surface compatibility.
Original price was: £11,000.00.£9,350.00Current price is: £9,350.00.
+vat
Best for: direct-object printing plus UV TPU badges and crystal labels.
Combine a 600 × 900 mm UV flatbed with transfer-production options; add the optional rotary fixture for suitable cylindrical items.
Objects print on the flatbed. Badges and crystal labels need separate media and finishing workflows; cylinders need the optional fixture.
Prices exclude VAT.
UV flatbed & transfer applications
The GD-6090UV Pro provides a 600 × 900 mm flatbed, three Epson I3200-U1 heads and white, CMYK and varnish UV ink. Specify your object, TPU badge and crystal-label workflows separately.
What you can make
Decorate suitable phone cases, gifts and other objects after checking their dimensions and surface compatibility.
Plan the correct film, artwork and finishing method for each transfer application.
Discuss the optional electric rotary fixture for bottles, cups and other compatible cylindrical items.
Application examples depend on the correct configuration, consumables and finishing process. Test the actual material before production.
Know the machine
| Specification | Details |
|---|---|
| Printing format | UV flatbed with additional transfer applications |
| Print area | 600 × 900 mm |
| Maximum media height | 180 mm |
| Printheads | 3 Epson I3200-U1 |
| Ink | Grando UV ink: white + CMYK + varnish |
| Maximum resolution listed | 2400 dpi |
| Curing | Dual UV LED lights |
| Interface | Gigabit Ethernet |
| Dimensions with stand | 1572 × 1460 × 990 mm (W × D × H) |
| Weight with stand | 300 kg |
| Listed power | 1300 W |
| Operating environment | 15–32°C; 35–70% RH, no condensation |
The figures above reproduce the manufacturer specifications listed on this product page. Confirm the supplied configuration and installation requirements in your itemised quotation.
From artwork to finished item
Check material, dimensions and surface preparation. Some substrates may need preparation or primer.
Use the correct flatbed layout or optional fixture with a confirmed ink and media setup.
Test adhesion and appearance on the intended item. Complete any separate badge or crystal-label finishing process.
Before you order
An application or optional fixture shown in the catalogue does not establish what is included. Have the supplied equipment, consumables, software and services clearly itemised.
Test the actual production item; the substrate name alone does not establish adhesion or durability.
Itemise compatible film, ink setup, cutting and pressing where required for badges, and the separate crystal-label process.
Confirm item shape, diameter, length and usable print area. The 180 mm media-height limit is not a verified cylinder-diameter limit.
Check the installed footprint, handling access, operating conditions, RIP software and any finishing equipment.
A few useful answers
Match the machine to your actual materials and finished product. A representative sample can help confirm the setup you need.
These applications are supported with the right configuration and consumables. Each needs its own preparation and finishing process.
The manufacturer identifies it as optional. Include it explicitly in the quotation if you need cylindrical printing.
The GD-6090UV Pro uses a 600 × 900 mm flatbed and supports direct-object work. The GD-600S is a 600 mm roll-fed film printer for TPU badges and crystal labels.
No. That figure is the maximum listed media height. The optional rotary fixture needs its own confirmed item dimensions and usable print area.
Those claims are not established by this listing. Obtain application-specific evidence before promising either property for a finished product.
Related products
Compare the relevant supplies, services and alternative equipment below. Confirm consumable compatibility with the exact configuration before ordering.
CMYK and white options; confirm the approved formulation for the machine and application.
Clear-finish ink to confirm against the supplied UV setup.
A smaller 297 × 420 mm hybrid flatbed with optional fixtures.
A 600 mm media-width roll-fed platform for badge and crystal-label workflows.
Talk through your application
Tell us the item materials, dimensions and intended finish. Include any TPU badges, crystal labels or cylindrical products you plan to make.
Discuss your setupCall 01324 610156 or email sales@dtfsupplies.co.uk.
The Grando GD-6090UV Pro is a multifunction UV flatbed for decorating objects and producing UV TPU badges and crystal labels. Its 600 × 900 mm area accommodates larger pieces or layouts of smaller items.
Three Epson I3200-U1 heads use white, CMYK and varnish UV ink. The sheet lists CCD camera positioning and a vacuum flatbed, with an optional electric cylinder fixture for suitable round objects.
| Specification | Details |
|---|---|
| Printing format | UV flatbed with additional transfer applications |
| Print area | 600 × 900 mm |
| Maximum media height | 180 mm |
| Printheads | 3 Epson I3200-U1 |
| Ink | Grando UV ink: white + CMYK + varnish |
| Maximum resolution listed | 2400 dpi |
| Curing | Dual UV LED lights |
| Interface | Gigabit Ethernet |
| Dimensions with stand | 1572 × 1460 × 990 mm (W × D × H) |
| Weight with stand | 300 kg |
| Listed power | 1300 W |
| Operating environment | 15–32°C; 35–70% RH, no condensation |
Figures above are manufacturer specifications. Confirm the supplied configuration and installation requirements in your quotation.
For objects, confirm the material, surface preparation, height and arrangement. Some substrates may need preparation or primer; test adhesion and finish on production samples.
TPU badges and crystal labels are separately confirmed applications. Specify the film, ink setup and finishing equipment for each. Badge production can require cutting and heat pressing; crystal labels use a different transfer workflow.
The electric rotary fixture is optional. Confirm item shape, diameter, length and usable print area. The 180 mm media-height limit is not a verified maximum cylinder diameter.
Have fixtures, RIP software and finishing equipment listed in the quotation. No universal adhesion, wash-resistance, dishwasher-safety or food-contact claim is made.
These applications are supported with the right configuration and consumables. Each needs its own preparation and finishing process.
The manufacturer identifies it as optional. Include it explicitly in the quotation if you need cylindrical printing.
The GD-6090UV Pro uses a 600 × 900 mm flatbed and supports direct-object work. The GD-600S is a 600 mm roll-fed film printer for TPU badges and crystal labels.
Tell us what you want to print, the material and dimensions, and your expected order volume. Ask for an itemised quotation, call 01324 610156 or email sales@dtfsupplies.co.uk.
